제품 상세 정보:
|
| 작동 압력: | 1.5~8(바) | 작동 속도: | 100~500(mm/s) |
|---|---|---|---|
| 최대 스트로크: | 600(Mm) | 작동 온도: | -25 ～ +80(℃) |
| 실린더 보어: | 80(mm) | 재료: | 알류미늄 |
| 강조하다: | JB Model Pneumatic Air Cylinder,1.5-8 Bar Operating Pressure Air Cylinder,100-500 mm/s Operating Speed Pneumatic Cylinder |
||
II. Model
III. Main Technical Parameters
| Cylinder Bore(mm) | 80 | 100 | 125 | 160 | 180 | 200 | 250 | 320 | 400 |
| Maximum Stroke(mm) | 600 | 800 | 1000 | 1250 | 1600 | ||||
| Working Medium | Compressed air that has been purified and contains oil mist | ||||||||
| Operating Temperature Range(℃) | -25～+80(under non-freezing conditions) | ||||||||
| Operating Pressure Range (bar) | 1.5～8 | ||||||||
| Operating Speed Range(mm/s) | 100～500 | ||||||||
IV. Graphical Symbols and Outline Dimensions
